LingYI-Charge Mobile EV Charging Robot
Charger-comes-to-car · App booking · Auto-docking
Autonomous mobile EV-charging robot for smart parks, commercial complexes and large parking lots. 100 kWh onboard storage, one-tap app booking, LiDAR SLAM navigation and computer-vision plug-in — upgrading fixed chargers into a 'charger-comes-to-car' service.
Key features
01
App booking + autonomous navigation
Users book via QR or app; the robot plans its route to the target stall and copes with weak-GPS underground garages.
02
Vision-guided auto plug-in
RGB-D depth camera locates the charging port; the robotic arm docks autonomously — no human assistance needed.
03
Cloud fleet scheduling
Multi-robot coordination by battery, location and booking queue — maximizing uptime and service efficiency.
Business value
Reference ROI: two units at a 200-bay complex serve 12–16 cars/day at ¥60 avg — ¥22k–29k/month, payback ~8–12 months.
Technical specifications
Chassis
- Dimensions
- 1200 × 800 × 650 mm
- Curb weight
- 180 kg
- Rated load
- 2 t
Energy & charging
- Battery capacity
- 100 kWh
- Power input
- 220V AC inverter
- Fast-charge input
- 750 W
- Charging efficiency
- ≥ 94%
Navigation & sensing
- Positioning
- Laser SLAM + vision fusion
- Accuracy
- ± 15 cm
- Obstacle avoidance
- 360° multi-sensor (ultrasonic + depth camera)
Mobility
- Top speed
- 1.5 m/s
- Max gradient
- ≤ 10°
Protection & comms
- Ingress rating
- IP54
- Connectivity
- 4G / 5G + Wi-Fi
Safety
- Battery protection
- Multi-level BMS
- Emergency stop
- Hardware E-stop + software safety edge
